VISION PLUS Sliding Door System
The Vision PLUS is Vetrina’s premium sliding door designed for large openings with a sleek look and top performance. It has ultra-thin frames—25 mm interlock, side frames around 57 mm, and top/bottom at 68.5 mm—allowing up to 94% glass coverage. Built for large spaces, it supports sashes up to 4 m by 4 m, handles up to six panels spanning 78 feet, and fits glass thicknesses from 36 to 56 mm.
Massive Panels & Slim Profiles - Interlock width: 25 mm; vents and frames optimized to maximize glass area. Capable of handling sashes up to 43 square feet; multi-panel setups (up to six on three rails) for wide panoramic views.
High Load Capacity & Motorization - Sashes weighing up to 880 pounds can be fully pocketed into the frame, hiding them completely when closed.
Thermal & Acoustic Performance - Thermal transmittance: Uw ≥ 0.16 Btu/h·ft²·F. Soundproofing up to 43 dB. Excellent air and wind resistance properties.
Seamless Integration - Frames and sashes can be set flush with floors, walls, and ceilings to create barrier-free transitions. Hidden thresholds and pocketing ensure smooth indoor–outdoor connection.
Security & Easy Operation - Reinforced stainless steel rollers provide smooth sliding; multi-point locks (with key options) are discreetly built-in.
Design Flexibility - Configurable from 2 to 6 sashes across 1–3 tracks, including corner and pocket options. Finishes include powder coat (single/dual RAL, textured, wood effect), anodized, and antibacterial coatings.
The Vision PLUS is Vetrina’s premium sliding door designed for large openings with a sleek look and top performance. It has ultra-thin frames—25 mm interlock, side frames around 57 mm, and top/bottom at 68.5 mm—allowing up to 94% glass coverage. Built for large spaces, it supports sashes up to 4 m by 4 m, handles up to six panels spanning 78 feet, and fits glass thicknesses from 36 to 56 mm.
Massive Panels & Slim Profiles - Interlock width: 25 mm; vents and frames optimized to maximize glass area. Capable of handling sashes up to 43 square feet; multi-panel setups (up to six on three rails) for wide panoramic views.
High Load Capacity & Motorization - Sashes weighing up to 880 pounds can be fully pocketed into the frame, hiding them completely when closed.
Thermal & Acoustic Performance - Thermal transmittance: Uw ≥ 0.16 Btu/h·ft²·F. Soundproofing up to 43 dB. Excellent air and wind resistance properties.
Seamless Integration - Frames and sashes can be set flush with floors, walls, and ceilings to create barrier-free transitions. Hidden thresholds and pocketing ensure smooth indoor–outdoor connection.
Security & Easy Operation - Reinforced stainless steel rollers provide smooth sliding; multi-point locks (with key options) are discreetly built-in.
Design Flexibility - Configurable from 2 to 6 sashes across 1–3 tracks, including corner and pocket options. Finishes include powder coat (single/dual RAL, textured, wood effect), anodized, and antibacterial coatings.
The Vision PLUS is Vetrina’s premium sliding door designed for large openings with a sleek look and top performance. It has ultra-thin frames—25 mm interlock, side frames around 57 mm, and top/bottom at 68.5 mm—allowing up to 94% glass coverage. Built for large spaces, it supports sashes up to 4 m by 4 m, handles up to six panels spanning 78 feet, and fits glass thicknesses from 36 to 56 mm.
Massive Panels & Slim Profiles - Interlock width: 25 mm; vents and frames optimized to maximize glass area. Capable of handling sashes up to 43 square feet; multi-panel setups (up to six on three rails) for wide panoramic views.
High Load Capacity & Motorization - Sashes weighing up to 880 pounds can be fully pocketed into the frame, hiding them completely when closed.
Thermal & Acoustic Performance - Thermal transmittance: Uw ≥ 0.16 Btu/h·ft²·F. Soundproofing up to 43 dB. Excellent air and wind resistance properties.
Seamless Integration - Frames and sashes can be set flush with floors, walls, and ceilings to create barrier-free transitions. Hidden thresholds and pocketing ensure smooth indoor–outdoor connection.
Security & Easy Operation - Reinforced stainless steel rollers provide smooth sliding; multi-point locks (with key options) are discreetly built-in.
Design Flexibility - Configurable from 2 to 6 sashes across 1–3 tracks, including corner and pocket options. Finishes include powder coat (single/dual RAL, textured, wood effect), anodized, and antibacterial coatings.
Combining refined minimalism with robust performance, Vetrina Vision PLUS brings monumental scale and elegance to architectural projects. Its ultra-thin sightlines and expansive glass offer immersive views and an abundance of natural light. The system ensures thermal comfort, acoustic privacy, and enhanced security—all within a structural framework that provides smooth, effortless operation and a flush, integrative design. Whether for grand residences or statement commercial spaces, it delivers unparalleled form and function.
